HR12-1000W
HR12-1000W (12V - 1000W)
HR ( High Rate ) series Valve Regulated Lead Acid (VRLA) battery is designed for heavy load discharge applications with 15 years design life in float service. By using strong grids, thick plate and specially designed active material. It is with lower I.R, lower self discharge rate, high power, and longer service life. The HR series battery offers 30% more power output than the standard series. It is suitable for high power standby used, such as datacenter, UPS, EPS etc.
.
Downloads
| Specification Item | Technical Parameter |
|---|---|
| Cells Per Unit | 6 |
| Voltage Per Unit | 12V |
| Capacity | 1000W @ 15min-rate to 1.67V per cell @ 25°C |
| Weight | Approx. 80.5Kg (Tolerance ±5%) |
| Internal Resistance | ≤2.2 mΩ(Full Charge Condition @25℃) |
| Terminal | Default F10(M8) |
| Max. Discharge Current | 2600A (5 sec) |
| Short Circuit Current | 4600A |
| Design Life | 15 years |
| Max. Charging Current | 78.0 A |
| Container Material | A.B.S. UL94-HB (UL94-V0 Optional) |
| Operating Temperature Range | Discharge: -20°C~60°C Charge: 0°C~50°C Storage: -20°C~60°C |
| Normal Operating Temperature | 25℃±5℃ |
